Multi-purpose Rear Projection Diffusion Screen

Diffusion coatings are available for all types of applications with any size screen and a wide range of viewing angles.

Five unique optical coatings to choose from (see below) to match your application requirements.

Diffusion coating is permanently bonded to the substrate. Cannot peel off like laminated film or vinyl based diffusion screens.

Two substrates offered: Da-Glas (glass substrate) available standard in sizes up to 10'H x 20'W and

Da-Plex (acrylic substrate) available in standard sizes up to 9'H x 18'W. Larger sizes available upon request.

Three factory framing options are offered: Standard frame, Deluxe frame and Self-trimming frame.

Please contact Da-Lite Sales Partners for pricing and additional specification information.

	Video Vision
Ideal for video projection under controlled lighting conditions offering an exceptionally wide viewing cone and a uniform, bright, sharp image with no color shift.

	DA-100
Provides a neutral gray appearance with an on axis gain of 1. Well suited for high resolution applications. (formerly DA-WA N)

	DA-150
A neutral white screen coating providing a 1.5 gain and excellent off axis viewing under controlled, low level ambient light conditions. (formerly DA-WA)

	DA-180
An ideal coating for multi-image displays where bend angles from some images may be severe. Offers a 1.8 center gain and a generous viewing cone of 60°. (formerly DA-1N)

	DA-230
Perfect for high ambient room lighting conditions. Offers a 2.3 gain and a 50° viewing cone. (formerly DA-3N)

Optional Finishes and Tint
PROTEK II^® Da-Lite's Polacoat screens are available with a factory applied protective coating to minimize the possibility of accidental surface damage.
HIGH CONTRAST TINT This feature significantly enhances the perceived quality of all video images. By making the dark elements of an image appear even darker preceived contrast is greatly increased. Note: Not to be used with Video Vision or DA-150 coatings.
